Configure workshop presses

H-Type Workshop Press

Step 1 of 7 - Trin 1

14%

Select size

Størrelse(Required)

25T

40T

60T

100T

200T

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

Our standard program is designed and manufactured in Denmark with high quality European components and low energy IE3 motors. The frame is conservatively designed and fully welded for extra high rigidity and tolerance. The presses are CE marked according to European standards.

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-H 25	WP-H 40	WP-H 60	WP-H 100	WP-H 200
Pressing force, max.		[kN]	250	400	600	1000	2000
Stroke		[mm]	400	400	400	400	400
Daylight, min.	A	[mm]	300	300	300	300	300
Daylight, max.	B	[mm]	900	900	900	900	900
Table width between verticals	C	[mm]	740	850	1010	1080	1150
Total Width	D	[mm]	1215	1320	1560	1730	1920
Side clearance	E	[mm]	160	245	290	360	460
Max floor space	F	[mm]	670	650	760	800	1040
Overall height	G	[mm]	2050	2150	2275	2500	2500
Bed height, max.	H	[mm]	1010	1045	1145	1245	1245
Press bed adjustment	I	[mm]	4x150	4x150	4x150	4x150	4x150
Moveable cylinder	J	[mm]	250*	275*	330*	340*	280*
Weight (Approx)		[kg]	300	500	800	1300	2100
MOTOR PUMP UNIT
Pressing speed		[mm/s]	10/10	9/9	10/5	8/3	10/2,5
Return speed		[mm/s]	16	12	14	11	14
Return load, max.		[kN]	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	5,5
Oil reserve capacity		[L]	25	25	25	25	80

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-H 25	WP-H 40	WP-H 60	WP-H 100	WP-H 200
Pressing force, max.		[kN]	250	400	600	1000	2000
Stroke		[mm]	400	400	400	400	400
Daylight, min.	A	[mm]	300	300	300	300	300
Daylight, max.	B	[mm]	900	900	900	900	900
Table width between verticals	C	[mm]	740	850	1010	1080	1150
Total Width	D	[mm]	1215	1320	1560	1730	1920
Side clearance	E	[mm]	160	245	290	360	460
Max floor space	F	[mm]	670	650	760	800	1040
Overall height	G	[mm]	2050	2150	2275	2500	2500
Bed height, max.	H	[mm]	1010	1045	1145	1245	1245
Press bed adjustment	I	[mm]	4x150	4x150	4x150	4x150	4x150
Moveable cylinder	J	[mm]	250*	275*	330*	340*	280*
Weight (Approx)		[kg]	300	500	800	1300	2100
MOTOR PUMP UNIT
Pressing speed		[mm/s]	10/10	9/9	10/5	8/3	10/2,5
Return speed		[mm/s]	16	12	14	11	14
Return load, max.		[kN]	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	5,5
Oil reserve capacity		[L]	25	25	25	25	80

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-H 25	WP-H 40	WP-H 60	WP-H 100	WP-H 200
Pressing force, max.		[kN]	250	400	600	1000	2000
Stroke		[mm]	400	400	400	400	400
Daylight, min.	A	[mm]	300	300	300	300	300
Daylight, max.	B	[mm]	900	900	900	900	900
Table width between verticals	C	[mm]	740	850	1010	1080	1150
Total Width	D	[mm]	1215	1320	1560	1730	1920
Side clearance	E	[mm]	160	245	290	360	460
Max floor space	F	[mm]	670	650	760	800	1040
Overall height	G	[mm]	2050	2150	2275	2500	2500
Bed height, max.	H	[mm]	1010	1045	1145	1245	1245
Press bed adjustment	I	[mm]	4x150	4x150	4x150	4x150	4x150
Moveable cylinder	J	[mm]	250*	275*	330*	340*	280*
Weight (Approx)		[kg]	300	500	800	1300	2100
MOTOR PUMP UNIT
Pressing speed		[mm/s]	10/10	9/9	10/5	8/3	10/2,5
Return speed		[mm/s]	16	12	14	11	14
Return load, max.		[kN]	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	5,5
Oil reserve capacity		[L]	25	25	25	25	80

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-H 25	WP-H 40	WP-H 60	WP-H 100	WP-H 200
Pressing force, max.		[kN]	250	400	600	1000	2000
Stroke		[mm]	400	400	400	400	400
Daylight, min.	A	[mm]	300	300	300	300	300
Daylight, max.	B	[mm]	900	900	900	900	900
Table width between verticals	C	[mm]	740	850	1010	1080	1150
Total Width	D	[mm]	1215	1320	1560	1730	1920
Side clearance	E	[mm]	160	245	290	360	460
Max floor space	F	[mm]	670	650	760	800	1040
Overall height	G	[mm]	2050	2150	2275	2500	2500
Bed height, max.	H	[mm]	1010	1045	1145	1245	1245
Press bed adjustment	I	[mm]	4x150	4x150	4x150	4x150	4x150
Moveable cylinder	J	[mm]	250*	275*	330*	340*	280*
Weight (Approx)		[kg]	300	500	800	1300	2100
MOTOR PUMP UNIT
Pressing speed		[mm/s]	10/10	9/9	10/5	8/3	10/2,5
Return speed		[mm/s]	16	12	14	11	14
Return load, max.		[kN]	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	5,5
Oil reserve capacity		[L]	25	25	25	25	80

STANDARD PROGRAM, Workshop Presses, H-Type, 200T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-H 25	WP-H 40	WP-H 60	WP-H 100	WP-H 200
Pressing force, max.		[kN]	250	400	600	1000	2000
Stroke		[mm]	400	400	400	400	400
Daylight, min.	A	[mm]	300	300	300	300	300
Daylight, max.	B	[mm]	900	900	900	900	900
Table width between verticals	C	[mm]	740	850	1010	1080	1150
Total Width	D	[mm]	1215	1320	1560	1730	1920
Side clearance	E	[mm]	160	245	290	360	460
Max floor space	F	[mm]	670	650	760	800	1040
Overall height	G	[mm]	2050	2150	2275	2500	2500
Bed height, max.	H	[mm]	1010	1045	1145	1245	1245
Press bed adjustment	I	[mm]	4x150	4x150	4x150	4x150	4x150
Moveable cylinder	J	[mm]	250*	275*	330*	340*	280*
Weight (Approx)		[kg]	300	500	800	1300	2100
MOTOR PUMP UNIT
Pressing speed		[mm/s]	10/10	9/9	10/5	8/3	10/2,5
Return speed		[mm/s]	16	12	14	11	14
Return load, max.		[kN]	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	5,5
Oil reserve capacity		[L]	25	25	25	25	80

This field is hidden when viewing the form

Unavngivet

200T

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

This field is hidden when viewing the form

Step 2

Drift function

25T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

40T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

60T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

60T step 2 - Elektrisk fodbejtening

Auto sequence with sliding doors

Auto sequence with light guard

100T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

100T step 2 - Elektrisk fodbejtening

Auto sequence with sliding doors

Auto sequence with light guard

200T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%

Electrical control with Siemens 7’’ touch panel

Adjustable top position
Reversal functions
Adjustable position control or adjustable press force
Auto return of piston to top position with timer function
Stroke Counter
Including press flange and rotation protection of piston
3 position safety foot operation with 2m hand free operation

Ideal for mounting and small production work.

Electrical control with Siemens 7’’ touch panel

Adjustable top position
Reversal functions
Adjustable position control or adjustable press force
Auto return of piston to top position with timer function
Stroke Counter
Including press flange and rotation protection of piston
Including 2 hand operation used to protect the operator’s hands.

Ideal for mounting and small production work

This option allows you to select automatic sequence execution, allowing the operator to prepare the next item while the sequence executes.

For full security this solution includes fixed shielding on the sides and in the back. The front is supplied with sliding drawers with a safety switch that ensure that the doors are closed before the sequence is started.

The control is supplied with a key switch, where you can choose between manual and automatic sequence execution. In manual mode, the machine can be operated with the front doors open.

Front doors and side cover are supplied with 4 mm transparent polycarbonate plate.

This field is hidden when viewing the form

Unavngivet

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

Position Control, Pressure Stop and Auto - 2-hand operation

Position Control, Pressure Stop and Auto - 2-hand operation

Position Control, Pressure Stop and Auto - 2-hand operation

Position Control, Pressure Stop and Auto - 2-hand operation

Auto sequence with sliding doors

Auto sequence with sliding doors

Auto sequence with sliding doors

Auto sequence with sliding doors

Auto sequence with sliding doors

Auto sequence with light guard

Auto sequence with light guard

Auto sequence with light guard

Auto sequence with light guard

Auto sequence with light guard

Auto sequence with light guard

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

This field is hidden when viewing the form

Step 3

Extra options

Tilkøb af optioner - 25T - trin 3

Tool press flange

Bed plate kit

Straightening block kit

This field is hidden when viewing the form

Tilkøb af optioner - 25T - Elektrisk fodbetjening med 2 meter kabel- trin 3

Bed plate kit

Straightening block kit

This field is hidden when viewing the form

Tilkøb af optioner - 25T - Elektrisk fodbetjening med 2 meter kabel- trin 3

Bed plate kit

Straightening block kit

This field is hidden when viewing the form

Tilkøb af optioner - 25T - 2-håndsbetjening - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Tilkøb af optioner - 40T - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Tilkøb af optioner - 60T - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Guided ram plate with 2 columns

800 mm stroke

Tilkøb af optioner - 100T - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Guided ram plate with 2 columns

800 mm stroke

Tilkøb af optioner - 200T - trin 3

Bed plate kit

Straightening block kit

FUNCTION

Used for tool mounting and for when larger press surfaces are required.

SPECIFICATIONS

Model			WP-C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Hole pitch, press flange	V	[mm]	ø78	ø78	ø86	ø110	ø130
Thickness, press flange	X	[mm]	25	25	30	40	45
Hole diameter, press flange	Y	[mm]	4x ø9	4x ø9	4x ø11	4x ø13	4x ø17
Diameter, press flange	Z	[mm]	ø98	ø98	ø108	ø134	ø160

Model			WP-H/C 200
Hole pitch, press flange	V	[mm]	ø210
Center hole, press flange	W	Thread	M12
Thickness, press flange	X	[mm]	52
Hole diameter, press flange	Y	[mm]	4x ø22
Diameter, press flange	Z	[mm]	ø260

Machined solid S355 quality steel that can withstand heavy loads, with T-groove for mounting tools.

SPECIFIKATIONER

Model		WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100	WP-H/C 200
A	[mm]	300	300	400	400	500
B	[mm]	500	500	600	600	700
D	[mm]	14	14	14	14	18
G	[mm]	ø100	ø100	ø120	ø120	ø150
Weight	[KG]	62	62	175	175	390

Solid S355 quality steel, machined surfaces for great parallelism and fall protection, V-shaped back for pressing round items.

FUNCTION

Protects the press bed from direct pressure.

This field is hidden when viewing the form

Unavngivet

Tool press flange

Bed plate kit

Straightening block kit

Guided ram plate with 2 columns

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

This field is hidden when viewing the form

Step 4

Shielding

Tilkøb af optioner - 25T - Manuelt - trin 4

Sliding doors front

Guard kit for sides

Rear guard

Electrical door monitoring

Tilkøb af optioner - 40T, 60t, 100t - Manuelt - trin 4

Sliding doors front

Guard kit for sides

Rear guard

Electrical door monitoring

Tilkøb af optioner - 200T - Manuelt - trin 4

Sliding doors front

Guard kit for sides

Rear guard

Electrical door monitoring

FUNCTION

For increased safety under pressing.

SPECIFICATIONS

Transparent 4mm polycarbonate panels and low-friction rails..

FUNCTION

Prevents accidental access to the press area from the side

SPECIFIKATIONER

Transparent 4mm polycarbonate panels.Transparent for better monitoring

FUNCTION

Prevents accidental access to the press area from the back

SPECIFICATIONS

2mm Steel cover

FUNCTION

For increased safety under pressing. Secures no pressing with open doors.

Used in in combination with sliding door

This field is hidden when viewing the form

Unavngivet

Sliding doors front

Guard kit for sides

Rear guard

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

This field is hidden when viewing the form

25T step 5

Værktøj og tilbehør

5 af 7 trin

Tilkøb af optioner - 25T - 5

Arbor kit

Tool plate

Broaching Fixture

Værktøj og tilbehør - 40T - 5

Arbor kit

Tool plate

Broaching Fixture

Press Brake Tool

Værktøj og tilbehør - 200T - 5

Press Brake Tool

Set of 8 arbors in diameter ø12-14-16-18-20-22-25-30mm incl. suspension and adapter.

Used for pressing bearings and bushings on and off.

Teardrop shaped retaining plate, used for pin press support in combination with arbor set.

For easy handling of broach when making keyways on pulleys, clutches and other items.

Suitable for H-Frame presses from 40-200t. Maximum tool width: 835 mm.

The lower tool has 4 pcs. 85 deg. dies, 16, 22, 35 og 50 mm.

Can be used for sheet thicknesses from 0,5 til 6 mm. Maximum presse force: 45 ton.

STENHOJ high quality hydraulic oil. 25-100t WP -> 1 can. 200 Ton presses -> 4 cans.

Order STENHOJ hydraulic oil together with your standard workshop press and receive one year extended warranty (3 years) *

* wear and tear parts excluded

Hydraulic Oil ISO VG 46, 20 liter Quantity

Price: 90,00 €

Quantity

This field is hidden when viewing the form

Unavngivet

Arbor kit

Værktøjsplade

Rømmekonsol

Hydraulic Oil ISO VG 46, 20 liter

Kantbukkeværktøj

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

Summary – request a quote for the following

Unsure whether the product meets your needs?

Talk to a specialist about your needs and options

Contact

H-type

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

Final step

7 af 7 trin

Dine oplysninger

Navn(Required)

First Last

Virksomhed

E-mail(Required)

Telefon

Select country

Besked

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

C-Type Workshop Presses

Step 1 of 6 - Trin 1

16%

Select size

Størrelse(Required)

20T

25T

40T

60T

100T

200T

STANDARD PROGRAM - Workshop Presses, C-Type, 20T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-C 20	WP-C 25	WP-C 40	WP-C 60	WP-C 100	WP-C 200
Pressing force, max.		[kN]	200	250	400	600	1000	2000
Stroke	A	[mm]	400	400	400	400	400	400
Daylight, max.	B	[mm]	302	600	600	600	600	600
Working depth (back to front)	C	[mm]	370	450	450	600	600	750
Throat depth	D	[mm]	220	300	300	400	400	500
Width	E	[mm]	542	684	709	807	862	1142
Overall height	F	[mm]	1275	2250	2300	2350	2375	2500
Total depth	G	[mm]	871	1100	1200	1400	1500	1800
Bed Height	H	[mm]	234	900	900	900	900	920
Internal frame width	I	[mm]	170	170	210	245	305	395
Weight (Approx)		[kg]	250	650	900	1350	1900	4200
Motor pump unit
Pressing speed		[mm/s]	10/10	10/10	10/10	9/9	10/5	10/4
Return speed		[mm/s]	16	16	13	14	11	20
Return load, max.		[kN]	30	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	4	5,5
Oil tank capacity		[L]	25	25	25	25	25	40

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-C 20	WP-C 25	WP-C 40	WP-C 60	WP-C 100	WP-C 200
Pressing force, max.		[kN]	200	250	400	600	1000	2000
Stroke	A	[mm]	400	400	400	400	400	400
Daylight, max.	B	[mm]	302	600	600	600	600	600
Working depth (back to front)	C	[mm]	370	450	450	600	600	750
Throat depth	D	[mm]	220	300	300	400	400	500
Width	E	[mm]	542	684	709	807	862	1142
Overall height	F	[mm]	1275	2250	2300	2350	2375	2500
Total depth	G	[mm]	871	1100	1200	1400	1500	1800
Bed Height	H	[mm]	234	900	900	900	900	920
Internal frame width	I	[mm]	170	170	210	245	305	395
Weight (Approx)		[kg]	250	650	900	1350	1900	4200
Motor pump unit
Pressing speed		[mm/s]	10/10	10/10	10/10	9/9	10/5	10/4
Return speed		[mm/s]	16	16	13	14	11	20
Return load, max.		[kN]	30	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	4	5,5
Oil tank capacity		[L]	25	25	25	25	25	40

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-C 20	WP-C 25	WP-C 40	WP-C 60	WP-C 100	WP-C 200
Pressing force, max.		[kN]	200	250	400	600	1000	2000
Stroke	A	[mm]	400	400	400	400	400	400
Daylight, max.	B	[mm]	302	600	600	600	600	600
Working depth (back to front)	C	[mm]	370	450	450	600	600	750
Throat depth	D	[mm]	220	300	300	400	400	500
Width	E	[mm]	542	684	709	807	862	1142
Overall height	F	[mm]	1275	2250	2300	2350	2375	2500
Total depth	G	[mm]	871	1100	1200	1400	1500	1800
Bed Height	H	[mm]	234	900	900	900	900	920
Internal frame width	I	[mm]	170	170	210	245	305	395
Weight (Approx)		[kg]	250	650	900	1350	1900	4200
Motor pump unit
Pressing speed		[mm/s]	10/10	10/10	10/10	9/9	10/5	10/4
Return speed		[mm/s]	16	16	13	14	11	20
Return load, max.		[kN]	30	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	4	5,5
Oil tank capacity		[L]	25	25	25	25	25	40

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-C 20	WP-C 25	WP-C 40	WP-C 60	WP-C 100	WP-C 200
Pressing force, max.		[kN]	200	250	400	600	1000	2000
Stroke	A	[mm]	400	400	400	400	400	400
Daylight, max.	B	[mm]	302	600	600	600	600	600
Working depth (back to front)	C	[mm]	370	450	450	600	600	750
Throat depth	D	[mm]	220	300	300	400	400	500
Width	E	[mm]	542	684	709	807	862	1142
Overall height	F	[mm]	1275	2250	2300	2350	2375	2500
Total depth	G	[mm]	871	1100	1200	1400	1500	1800
Bed Height	H	[mm]	234	900	900	900	900	920
Internal frame width	I	[mm]	170	170	210	245	305	395
Weight (Approx)		[kg]	250	650	900	1350	1900	4200
Motor pump unit
Pressing speed		[mm/s]	10/10	10/10	10/10	9/9	10/5	10/4
Return speed		[mm/s]	16	16	13	14	11	20
Return load, max.		[kN]	30	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	4	5,5
Oil tank capacity		[L]	25	25	25	25	25	40

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-C 20	WP-C 25	WP-C 40	WP-C 60	WP-C 100	WP-C 200
Pressing force, max.		[kN]	200	250	400	600	1000	2000
Stroke	A	[mm]	400	400	400	400	400	400
Daylight, max.	B	[mm]	302	600	600	600	600	600
Working depth (back to front)	C	[mm]	370	450	450	600	600	750
Throat depth	D	[mm]	220	300	300	400	400	500
Width	E	[mm]	542	684	709	807	862	1142
Overall height	F	[mm]	1275	2250	2300	2350	2375	2500
Total depth	G	[mm]	871	1100	1200	1400	1500	1800
Bed Height	H	[mm]	234	900	900	900	900	920
Internal frame width	I	[mm]	170	170	210	245	305	395
Weight (Approx)		[kg]	250	650	900	1350	1900	4200
Motor pump unit
Pressing speed		[mm/s]	10/10	10/10	10/10	9/9	10/5	10/4
Return speed		[mm/s]	16	16	13	14	11	20
Return load, max.		[kN]	30	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	4	5,5
Oil tank capacity		[L]	25	25	25	25	25	40

STANDARD PROGRAM, Workshop Presses, C-Type, 200T

INCLUDED:

Manual Operation (variable pressing speed)
Digital gauge with press force in ton precision 0,1T
Double acting cylinder with 400mm stroke length
Replaceable nose cap
3m cord with cee plug

FEATURES:

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%
Flexible and easy adjustable daylight

SPECIFICATIONS

NOSE CAP

Model	WP-H/C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Diameter [mm]	ø60	ø60	ø65	ø85	ø100

QUESTIONS?
Having troubles figuring out which size fits your need? Have a look at the table below or contact our specialist team with questions or queries.

MODEL			WP-C 20	WP-C 25	WP-C 40	WP-C 60	WP-C 100	WP-C 200
Pressing force, max.		[kN]	200	250	400	600	1000	2000
Stroke	A	[mm]	400	400	400	400	400	400
Daylight, max.	B	[mm]	302	600	600	600	600	600
Working depth (back to front)	C	[mm]	370	450	450	600	600	750
Throat depth	D	[mm]	220	300	300	400	400	500
Width	E	[mm]	542	684	709	807	862	1142
Overall height	F	[mm]	1275	2250	2300	2350	2375	2500
Total depth	G	[mm]	871	1100	1200	1400	1500	1800
Bed Height	H	[mm]	234	900	900	900	900	920
Internal frame width	I	[mm]	170	170	210	245	305	395
Weight (Approx)		[kg]	250	650	900	1350	1900	4200
Motor pump unit
Pressing speed		[mm/s]	10/10	10/10	10/10	9/9	10/5	10/4
Return speed		[mm/s]	16	16	13	14	11	20
Return load, max.		[kN]	30	30	30	30	30	200
Motor power 3x400V, 50Hz		[kW]	4	4	4	4	4	5,5
Oil tank capacity		[L]	25	25	25	25	25	40

This field is hidden when viewing the form

Unavngivet

200T

20T

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

This field is hidden when viewing the form

Step 2

Drift function

20T step 2(Required)

Manuel operation

25T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

40T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

60T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

100T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

200T step 2(Required)

Manuel operation

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

Joystick control with stepless pressing speed 0-100%
Stepless adjustable pressing force 5-100%

Electrical control with Siemens 7’’ touch panel

Adjustable top position
Reversal functions
Adjustable position control or adjustable press force
Auto return of piston to top position with timer function
Stroke Counter
Including press flange and rotation protection of piston
3 position safety foot operation with 2m hand free operation

Ideal for mounting and small production work.

Electrical control with Siemens 7’’ touch panel

Adjustable top position
Reversal functions
Adjustable position control or adjustable press force
Auto return of piston to top position with timer function
Stroke Counter
Including press flange and rotation protection of piston
Including 2 hand operation used to protect the operator’s hands.

Ideal for mounting and small production work

This option allows you to select automatic sequence execution, allowing the operator to prepare the next item while the sequence executes.

The control is supplied with a key switch, where you can choose between manual and automatic sequence execution. In manual mode, the machine can be operated with the front doors open.

Front doors and side cover are supplied with 4 mm transparent polycarbonate plate.

This field is hidden when viewing the form

Unavngivet

Position Control, Pressure Stop and Auto - Electric foot operation with 2 meter cable

Position Control, Pressure Stop and Auto - 2-hand operation

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

This field is hidden when viewing the form

Step 3

Extra options

Tilkøb af optioner - 25T and 40T- trin 3

Tool press flange

Bed plate kit

Straightening block kit

This field is hidden when viewing the form

Tilkøb af optioner - 25T - Elektrisk fodbetjening med 2 meter kabel- trin 3

Bed plate kit

Straightening block kit

This field is hidden when viewing the form

Tilkøb af optioner - 25T - Elektrisk fodbetjening med 2 meter kabel- trin 3

Bed plate kit

Straightening block kit

This field is hidden when viewing the form

Tilkøb af optioner - 25T - 2-håndsbetjening - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Tilkøb af optioner - 20T - trin 3

Press flange

Bed plate

Straightening block

Tilkøb af optioner - 60T - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Tilkøb af optioner - 60T - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Tilkøb af optioner - 100T - trin 3

Tool press flange

Bed plate kit

Straightening block kit

Tilkøb af optioner - 200T - trin 3

Bed plate kit

Straightening block kit

FUNCTION

Used for tool mounting and for when larger press surfaces are required.

SPECIFICATIONS

Model			WP-C 20	WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100
Hole pitch, press flange	V	[mm]	ø78	ø78	ø86	ø110	ø130
Thickness, press flange	X	[mm]	25	25	30	40	45
Hole diameter, press flange	Y	[mm]	4x ø9	4x ø9	4x ø11	4x ø13	4x ø17
Diameter, press flange	Z	[mm]	ø98	ø98	ø108	ø134	ø160

Model			WP-H/C 200
Hole pitch, press flange	V	[mm]	ø210
Center hole, press flange	W	Thread	M12
Thickness, press flange	X	[mm]	52
Hole diameter, press flange	Y	[mm]	4x ø22
Diameter, press flange	Z	[mm]	ø260

Machined solid S355 quality steel that can withstand heavy loads, with T-groove for mounting tools.

SPECIFIKATIONER

Model		WP-H/C 25	WP-H/C 40	WP-H/C 60	WP-H/C 100	WP-H/C 200
A	[mm]	300	300	400	400	500
B	[mm]	500	500	600	600	700
D	[mm]	14	14	14	14	18
G	[mm]	ø100	ø100	ø120	ø120	ø150
Weight	[KG]	62	62	175	175	390

Solid S355 quality steel, machined surfaces for great parallelism and fall protection, V-shaped back for pressing round items.

FUNCTION

Protects the press bed from direct pressure.

This field is hidden when viewing the form

Unavngivet

Tool press flange

Bed plate kit

Straightening block kit

Guided ram plate with 2 columns

Press flange

Bed plate

Straightening block

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

This field is hidden when viewing the form

25T step 5

Værktøj og tilbehør

5 af 7 trin

Tilkøb af optioner - 20t,25T,40t,60t,100t - 5

Arbor kit

Tool plate

Broaching Fixture

Værktøj og tilbehør - 40T - 5

Arbor kit

Tool plate

Værktøj og tilbehør - 200T - 5

Press Brake Tool

Set of 8 arbors in diameter ø12-14-16-18-20-22-25-30mm incl. suspension and adapter.

Used for pressing bearings and bushings on and off.

Teardrop shaped retaining plate, used for pin press support in combination with arbor set.

For easy handling of broach when making keyways on pulleys, clutches and other items.

Suitable for H-Frame presses from 40-200t. Maximum tool width: 835 mm.

The lower tool has 4 pcs. 85 deg. dies, 16, 22, 35 og 50 mm.

Can be used for sheet thicknesses from 0,5 til 6 mm. Maximum presse force: 45 ton.

STENHOJ high quality hydraulic oil. 25-100t WP -> 1 can. 200 Ton presses -> 4 cans.

Order STENHOJ hydraulic oil together with your standard workshop press and receive one year extended warranty (3 years) *

* wear and tear parts excluded

Hydraulic Oil ISO VG 46, 20 liter Quantity

Price: 90,00 €

Quantity

This field is hidden when viewing the form

Unavngivet

Arbor kit

Værktøjsplade

Rømmekonsol

Hydraulic Oil ISO VG 46, 20 liter

Kantbukkeværktøj

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

Summary – request a quote for the following

Unsure whether the product meets your needs?

Talk to a specialist about your needs and options

Contact

H-type

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

Final step

7 af 7 trin

Dine oplysninger

Navn(Required)

First Last

Virksomhed

E-mail(Required)

Telefon

Select country

Besked

Overview

Subtotal

Shipping Calculated in the final step

Total

Need help?

Talk to a specialist at +45 31 60 20 00

or write to us at info@stenhyd.com

H-Type Workshop Press

C-Type Workshop Press

H-Type Production Press

C-Type Production Press

SERVO-Hydraulisk Production Presses

Production Lines

Soft Broaching Solutions

Hard Broaching Precision

Sustainable Dry Broaching

Advanced Automation

Truck Chassis Beam Bending Machine

Upgrades & Retrofits

Other Services

H-Type Workshop Press

Select size

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM - Workshop Presses, H-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM, Workshop Presses, H-Type, 200T

NOSE CAP

Overview

Need help?

Step 2

Drift function

Electrical control with Siemens 7’’ touch panel

Electrical control with Siemens 7’’ touch panel

Overview

Need help?

Step 3

Extra options

Overview

Need help?

Step 4

Shielding

Overview

Need help?

25T step 5

Værktøj og tilbehør

Overview

Need help?

Summary – request a quote for the following

Unsure whether the product meets your needs?

H-type

Overview

Need help?

Final step

Overview

Need help?

C-Type Workshop Presses

Select size

STANDARD PROGRAM - Workshop Presses, C-Type, 20T-100T

NOSE CAP

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM - Workshop Presses, C-Type, 25T-100T

NOSE CAP

STANDARD PROGRAM, Workshop Presses, C-Type, 200T

NOSE CAP

Overview

Need help?

Step 2

Drift function

Electrical control with Siemens 7’’ touch panel

Electrical control with Siemens 7’’ touch panel

Overview

Need help?

Step 3

Extra options

Overview

Need help?

25T step 5
